DMP-100

· Perfect for new pipeline builds, pipein-in-place repiacement, and working in tight spaces
· Small footprint, high efficiency, and precise elevation control
· Wide geological adaptability and strong obstacle handling capability
· Power head rotation: Danfoss closed pump+Poclain motor, high torque & high speed.

Request Quote

Introduction

· Perfect for new pipeline builds, pipein-in-place repiacement, and working in tight spaces

· Small footprint, high efficiency, and precise elevation control

· Wide geological adaptability and strong obstacle handling capability

· Power head rotation: Danfoss closed pump+Poclain motor, high torque & high speed.

DMP-100

Advantages

· Superior Construction Accuracy with Precise Elevation Control

· Strong Site Adaptability for Narrow Working Conditions

· Wide Geological Compatibility for Complex Ground Conditions

· High Construction Efficiency and Remarkable Economic Benefits

· Multi-functional Design with Broad Application Scenarios
