Commins engine: 221/2200kW/rpm
Model | ZT-75/150 |
Max torque(N.m) | 34000 |
Rotation speed(rpm) | 0-137 |
Max pulling/thrusting force(kN) | 750/1500 |
Pulling speed(m/min) | 0-40 |
Commins engine(kW/rpm) | 221/2200 |
Max mud pump displacement(L/min) | 600 |
Max mud pump pressure(Mpa) | 10 |
Entry angle(degree) | 10-18 |
Walking speed(km/h) | 2-3 |
Weight(kg) | 18000 |
Dimension(mm) | 9500*2260*2500 |
Rod size(mm) | φ102*4500 |
Reamer size(mm) | φ300-1000 |
